*Frame
Size: XS , S Alpha Platinum Aluminium, curved top tube, Removable Integrated Battery (RIB), tapered head tube, Control Freak internal routing, Motor Armour, Boost148, 12 mm thru axleSize: M , L , XL Alpha Platinum Aluminium, Removable Integrated Battery (RIB), tapered head tube, Control Freak internal routing, Motor Armour, Boost148, 12 mm thru axle
*Fork
Size: XS RockShox 35 Gold RL, DebonAir spring, Motion Control damper, lockout, tapered steerer, 44 mm offset, oversized crown for eMTB, Boost110, 15 mm Maxle Stealth, 80 mm travelSize: S , M , L , XL RockShox 35 Gold RL, DebonAir spring, Motion Control damper, lockout, tapered steerer, 44 mm offset, oversized crown for eMTB, Boost110, 15 mm Maxle Stealth, 120 mm travel
Max compatible fork travel
120mm (526mm axle-to-crown), XS: 80mm (492mm axle-to-crown)
*Wheel front
Size: XS , S Bontrager Line Comp 30, Tubeless Ready, 6-bolt, Boost110, 15 mm thru axle, 27.5"Size: M , L , XL Bontrager Line Comp 30, Tubeless Ready, 6-bolt, Boost110, 15 mm thru axle, 29"
*Wheel rear
Size: XS , S Bontrager Line Comp 30, Tubeless Ready, Rapid Drive 108, 6-bolt, Boost148, 12mm thru axle, 27.5"Size: M , L , XL Bontrager Line Comp 30, Tubeless Ready, Rapid Drive 108, 6-bolt, Boost148, 12mm thru axle, 29"
Skewer rear
Bontrager Switch thru-axle, removable lever
*Tyre
Size: XS , S Bontrager XR3 Team Issue, Tubeless-Ready, Inner Strength sidewall, aramid bead, 120 tpi, 27.5x2.35"Size: M , L , XL Bontrager XR3 Team Issue, Tubeless Ready, Inner Strength sidewall, aramid bead, 120 tpi, 29 x 2.40"
Rim strip
Bontrager TLR
Max tyre size
Frame: 29x2.60" or 27.5x2.80" (XS & S: 27.5x2.60"), Fork: See manufacturer
Battery
Bosch PowerTube 625Wh, smart system
Charger
Bosch standard 4A, 230V, smart system
*Computer
Size: XS , S , M , L , XL Bosch LED remote, smart systemSize: XS , S , M , L , XL Bosch Kiox 300, smart system
Motor
Bosch Performance Line CX, smart system, magnesium motor body, 85 Nm
Shifter
Shimano SLX M7100, 12-speed
Rear derailleur
Shimano XT M8100, long cage
Crank
E*thirteen E*spec Plus, 165 mm length
Chainring
E*thirteen, 36T, steel
Cassette
Shimano SLX M7100, 10-51T, 12-speed
Chain
Shimano SLX M7100, 12-speed
Pedal
VP-536 nylon platform
Max. chainring size
1x: 38T
Saddle
Bontrager Commuter Comp
*Seatpost
Size: XS , S TranzX JD-YSP18, 100 mm travel, internal routing, 31.6 mm, 361 mm lengthSize: M , L , XL TranzX JD-YSP18, 130mm travel, internal routing, 31.6 mm, 425 mm length
*Handlebar
Size: XS , S Bontrager alloy, 31.8 mm, 15 mm rise, 720 mm widthSize: M , L , XL Bontrager alloy, 31.8 mm, 15 mm rise, 750 mm width
Grips
Bontrager XR Endurance Elite
*Stem
Size: XS Bontrager Rhythm Comp, 31.8 mm, 0-degree, 50 mm lengthSize: S , M Bontrager Rhythm Comp, 31.8mm, 0-degree, 60 mm lengthSize: L , XL Bontrager Rhythm Comp, 31.8 mm, 0-degree, 70 mm length
Head set
FSA IS-2, 1-1/8" top, 1.5" bottom
*Brake
Size: XS , S , M , L , XL SRAM DB 8 4-piston hydraulic discSize: XS , S , M , L , XL Shimano 4-piston hydraulic disc, M6100 lever, M6120 calliper
*Brake rotor
Size: XS , S SRAM CentreLine, 6-bolt, round-edge, 180 mmSize: XS , S , M , L , XL SRAM CentreLine, 6-bolt, round edge, 200 mmSize: XS , S Shimano RT66, 6-bolt, 180 mmSize: XS , S , M , L , XL Shimano RT66, 6-bolt, 203 mm
Rotor size
Max brake rotor sizes - Frame: 203mm, Fork: see fork manufacturer
Weight
M - 22.65 kg / 49.94 lbs (with TLR sealant, no tubes)
Weight limit
This bike has a maximum total weight limit (combined weight of bicycle, rider and cargo) of 136 kg (300 lb).
