*Frame
Size: XS , S Alpha Platinum Aluminium, curved top tube, Removable Integrated Battery (RIB), tapered head tube, Control Freak internal routing, Motor Armour, Boost148, 12 mm thru axleSize: M , L , XL Alpha Platinum Aluminium, Removable Integrated Battery (RIB), tapered head tube, Control Freak internal routing, Motor Armour, Boost148, 12 mm thru axle
*Fork
Size: XS RockShox Recon Silver RL, Solo Air, Motion Control damper, lockout, tapered steerer, 46 mm offset, Boost110, 15 mm Maxle Stealth, 80 mm travelSize: S RockShox Recon Silver RL, Solo Air, Motion Control damper, lockout, tapered steerer, 46 mm offset, Boost110, 15 mm Maxle Stealth, 120 mm travelSize: M , L , XL RockShox Recon Silver RL, Solo Air, Motion Control damper, lockout, tapered steerer, 42 mm offset, Boost110, 15 mm Maxle Stealth, 120 mm travel
Max compatible fork travel
120mm (526mm axle-to-crown), XS: 80mm (492mm axle-to-crown)
*Hub front
Size: XS , S , M , L , XL Shimano TC500 alloy, CentreLock, 110x15 mm thru axleSize: XS , S , M , L , XL Shimano MT400, CenterLock, Boost110, 15 mm thru-axle
*Hub rear
Size: XS , S , M , L , XL Shimano TC500 alloy, CentreLock, 148x12 mm thru axleSize: XS , S , M , L , XL Shimano MT510, CenterLock, Boost148, 12 mm thru-axle
Skewer rear
Bontrager Switch thru-axle, removable lever
*Rim
Size: XS , S , M , L , XL Bontrager Kovee, double-wall, Tubeless-Ready, 28-hole, 23 mm width, Presta valveSize: XS , S Bontrager Kovee, double-wall, Tubeless Ready, 28-hole, 23 mm width, Presta valve
*Tyre
Size: XS , S Bontrager XR3 Comp, wire bead, 30 tpi, 27.5x2.35"Size: M , L , XL Bontrager XR3 Comp, wire bead, 30 tpi, 29x2.30"
Max tyre size
Frame: 29x2.60" or 27.5x2.80" (XS & S: 27.5x2.60"), Fork: See manufacturer
Battery
Bosch PowerTube 625Wh, smart system
Charger
Bosch standard 4A, 230V, smart system
Controller
Bosch Intuvia 100, smart system
Computer
Bosch LED remote, smart system
Motor
Bosch Performance Line CX, smart system, magnesium motor body, 85 Nm
Shifter
Shimano Deore M6100, 12-speed
Rear derailleur
Shimano XT M8100, long cage
Crank
E*thirteen E*spec Plus, 165 mm length
Chainring
E*thirteen, 36T, steel
Cassette
Shimano Deore M6100, 10-51, 12-speed
Chain
Shimano Deore M6100, 12-speed
Pedal
VP-536 nylon platform
Max. chainring size
1x: 38T
Saddle
Bontrager Commuter Comp
*Seatpost
Size: XS , S Bontrager alloy, 31.6 mm, 12 mm offset, 330 mm lengthSize: M Bontrager alloy, 31.6 mm, 12 mm offset, 360 mm lengthSize: L , XL Bontrager alloy, 31.6 mm, 12 mm offset, 400 mm length
*Handlebar
Size: XS , S Bontrager alloy, 31.8 mm, 15 mm rise, 720 mm widthSize: M , L , XL Bontrager alloy, 31.8 mm, 15 mm rise, 750 mm width
Grips
Bontrager XR Endurance Comp, lock-on
*Stem
Size: XS Bontrager Comp, 31.8 mm, Blendr compatible, 7-degree, 50 mm lengthSize: S , M Bontrager Comp, 31.8 mm, Blendr compatible, 7-degree, 60 mm lengthSize: L , XL Bontrager Comp, 31.8 mm, Blendr compatible, 7-degree, 70 mm length
Head set
FSA IS-2, 1-1/8" top, 1.5" bottom
*Brake
Size: XS , S , M , L , XL Shimano 4-piston hydraulic disc, MT4100 lever, MT420 calliperSize: M , L , XL Tektro HD-M745 4-piston hydraulic disc
*Brake rotor
Size: XS , S Tektro, CentreLock, 180 mmSize: XS , S , M , L , XL Tektro, CentreLock, 203 mm
Rotor size
Max brake rotor sizes - Frame: 203mm, Fork: see fork manufacturer
Weight
M - 23.70 kg / 52.25 lbs (with tubes)
Weight limit
This bike has a maximum total weight limit (combined weight of bicycle, rider and cargo) of 136 kg (300 lb).
